₹4,952.00 (excluding 18% GST)
10 In stock
CompareNPB-120-12TB series is a 120W charger for compatible with lead-acid (Flooded, Gel, AGM) and li-ion(Lithium iron, lithium manganese) batteries. This product is a class I power unit (with FG), equipped with a standard IEC320-C14 AC inlet and two or three-stage charging control. The entire series supplies different models with output voltages ranging between 10.5VDC and 60.8VDC that can satisfy the demands for various types of batteries devices.
| MEAN WELL | |
| Product Category: | Battery Chargers |
| Brand: | MEAN WELL |
| Maximum Operating Temperature: | + 70 C |
| Minimum Operating Temperature: | – 30 C |
| Product Type: | Battery Chargers |
| Subcategory: | Battery |
| Unit Weight: | 1.3 kg |
. 90~264Vac universal AC input, built-in PFC
. Charger for compatible with lead-acid and li-ion batteries
. Fanless design
· Wide adjustable output range by VR:
Charging voltage adjustable(10.5~15.2V, 21~30.4V, 42~60.8V)
Charging current adjustable(50~100% rated current)
. 2 or 3 stage selectable by DIP S.W
. No load power consumption< 0.15W(AC S.W off)
. -30℃~+70℃ wide operating temperature
. Protections: Short circuit / Over voltage /Over temperature /
Battery reverse polarity protection
. Comply with UL/EN62368-1 and EN60335-1/2-29 dual certification
. Front panel LED indicator for charging status
. 3 years warranty
