GST160A20-R7B


MEAN WELL GST160A20-R7B

AC-DC Power Supply, Desktop Adaptor, 160W, 20V/8A, Level VI, GS160A Series

Note: Any order placed will take 12-15 days for dispatch.

4,621.00 (excluding 18% GST)

Compare

Description

GST160A is a highly reliable, 160W desktop style single-output green adaptor series. This product is a
class I power unit (with FG), equipped with a standard IEC320-C14 AC inlet and adopting the input range
from 85VAC to 264VAC. The entire series supplies different models with output voltages ranging between
12VDC and 48VDC that can satisfy the demands for various types of consumer electronic devices.
With the efficiency up to 94% and the extremely low no-load power consumption below 0.15W,GST160A is
compliant with USA EISA 2007/DoE, Canada NRCan, Australia and New Zealand MEPS, Korea K-MEPS,EU ErP and
Code of Conduct (CoC) Version 5. The supreme feature allows the adaptor to save the energy when it is either
under the operating mode or the standby mode. The entire series utilizes the 94V-0 flame retardant plastic
case.GST160A is certified for the international safety regulations.

Specification

AC Plug included/required: Required
Region: Universal
Input Voltage: 85 VAC to 264 VAC, 120 VDC to 370 VDC
Number of Outputs: 1 Output
Output Power: 160 W
Output Voltage-Channel 1: 20 VDC
Output Current-Channel 1: 8 A
Industry: Industrial
Connector Type: DIN Connector
DC Output Connector: 4 Pin DIN Plug
DC Output Lead Length: 1.2 m
Efficiency: Level VI
Brand: MEAN WELL
Compliance: PSE
Load Regulation: Regulated
Mounting Style: Desktop
Packaging: Bulk
Product Type: Desktop AC Adapters
Subcategory: AC-DC Power Supply
Unit Weight: 660 g



Features

. Global certificates
. Universal AC input / Full range
. 3 pole AC inlet IEC320-C14,Class I power unit
. Built-in active PFC function
. No load power consumption<0.15W
. Energy efficiency Level VI
. Comply with EISA 2007/DoE,NRCan,AU/NZ MEPS,
EU ErP and CoC Version 5
. Protections: Short circuit / Overload / Over voltage
/ Over temperature
. -30~+70℃ wide range working temperature
. Fully enclosed plastic case
. LED indicator for power on
. Various DC plug quick adapter accessory available
. 3 years warranty

Datasheet

GST160A SPEC

Note

Image may be a representation. See specs for product details.
