Out of stock
Note: Any order placed will take 12-15 days for dispatch.
(excluding 18% GST)
Compare. 2:1 wide input range
. 4:1 wide input range (A / B Type Only)
. 1000VDC I/O isolation
· 3000VDC I/O isolation (Option)
. Built-in remote ON/OFF control
. Built-in EMI filter
. Protections: Short circuit / Overload
. Cooling by free air convection
· Single in line package
. 100% full load burn-in test
. Low cost / High reliability
. Modified models available: output 3.3V/9V
· 2 years warranty
| Manufacturer: | MEAN WELL | |
| Product Category: | Isolated DC/DC Converters – Through Hole | |
| Mounting Style: | Through Hole | |
| Number of Outputs: | 1 Output | |
| Output Power: | 2 W | |
| Input Voltage, Min: | 9 V | |
| Input Voltage, Max: | 18 V | |
| Output Voltage-Channel 1: | 12 V | |
| Output Current-Channel 1: | 167 mA | |
| Isolation Voltage: | 1 kV | |
| Minimum Operating Temperature: | – 40 C | |
| Maximum Operating Temperature: | + 85 C | |
| Package/Case: | SIP-8 | |
| Length: | 21.84 mm | |
| Width: | 9.14 mm | |
| Height: | 11.18 mm | |
| Product: | Isolated | |
| Brand: | MEAN WELL | |
| Efficiency: | 80 % | |
| Input Voltage: | 9 V to 18 V | |
| Product Type: | Isolated DC-DC Converters | |
| Subcategory: | DC-DC Converter | |
| Unit Weight: | 3 g |
