Description
LAD-600 series is a 600W economical AC/DC low profile security power supply with UPS function.
Adopting the input range from 90Vac to 264Vac (115Vac/230Vac selectable by switch) and supports
output 27.6V, 41.5V and 55.2Vdc. With high efficiency up to 91% and built-in AC, battery switch for easy
maintenance. In addition, LAD-600 series not only provide TTL signals for AC OK, battery disconnect,
battery reverse polarity (No damage), battery low detection, battery full and discharge, but also possess
UART version so the users can monitor and control the status of the units, that enhance easy way for
integration into security and fire systems directly.
Features
. Built-in battery charger UPS function
. TTL signals for status detection:
AC OK, Battery disconnect, Battery reverse polarity, Battery low,
Battery full and Discharge (Blank version only)
. UART Communication (U version only)
· Built-in buzzer alarm (U version only)
. Built-in AC and battery circuit ON/OFF switchs enhance safetyness
during maintenance
. Forced UPS mode for battery maintenance
. Protections: Short circuit / Overload / Over voltage /
Over temperature / Battery low voltage /
Battery reverse polarity (No damage)
. -20 ~ +60℃ wide operating temperature
. Output voltage adjustable (-20%~+5%) for CH1 by VR
. Suitable for lead acid and lithium-ion batteries
. Design refer to GB17945/GB4717(U version only) system requirement
. 1U low profile
· 3 years warranty
Note
Image may be a representation. See specs for product details.
